RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 466 of 765

Mar 7, 2023

(3) Processing flow (in single-transmission mode)

Figure 12-72. Timing Chart of UART Transmission (in Single-Transmission Mode)

Shift

TxDq pin

Data transmissionData transmissionData transmission

SSmn

STmn

SEmn

SDRmn

INTSTq

TSFmn

Transmit data 1 Transmit data 2 Transmit data 3

Transmit data 1 Transmit data 2

Shift operation

Transmit data 3ST P SP ST P SP ST P SP

Shift operation Shift operation

Remark m: Unit number (m = 0), n: Channel number (n = 0), q: UART number (q = 0), mn = 00
