RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 475 of 765

Mar 7, 2023

(3) Processing flow

Figure 12-80. Timing Chart of UART Reception

Shift

RxDq pin

Data receptionData receptionData reception

SSmn

STmn

SEmn

SDRmn

INTSRq

TSFmn

Receive data 1 Receive data 2

Receive data 1 Receive data 2 Receive data 3ST P SP ST P ST PSP

Shift operation Shift operation Shift operation

Receive data 3

Remark m: Unit number (m = 0), n: Channel number (n = 1), r: Channel number (r = n – 1),

q: UART number (q = 0), mn = 01
