3.Preventive Maintenance
95
Paper Transfer Quality Standards
Engines
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
Back of the paper when performing duplex
printing:
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
± 1.2 mm/200 mm or less (B5 SEF or
more)
± 1.0 mm/100 mm or less (Less than B5
SEF)
Duplex:
± 1.0 mm/100 mm or less (B5 SEF or
more)
± 1.5 mm/100 mm or less (Less than B5
SEF)
Not applicable to paper fed from the bypass tray
(Reference value when using the bypass tray: ± 1.0
mm/100 mm)
20 mm or less from the leading and
trailing edges with a radius of 40 mm or
greater.
SPDF
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
± 2.0 mm/200 mm or less (B5 SEF or more)
± 2.5 mm/200 mm or less (Less than B5 SEF)
Duplex:
± 2.5 mm/100 mm or less
(ream weight)
Single Side: 45-110 kg
Duplex: 45-90 kg
These standards are determined using standard paper under standard conditions.
Values may vary depending on environmental conditions such as temperature, humidity, use of used paper, etc.
