4.Replacement
and Adjust
ment
168
SPDF Original T
ray
1.
Remove the S
PDF fr
ont cover
. (
SPDF
Front
Cover
)
2.
Remove the S
PDF r
ear cover
.
(
SPDF Rear Cov
er
)
3.
Slide the SPD
F original tray [
A] to r
emove it.
Original F
eed Unit
1.
Open the SPD
F top cover [A]
.
2.
Slide the original f
eed unit [B]
toward
s
the r
ear
to r
emove it.
SPDF Friction Pad
1.
Remove the origin
al feed unit
. (
Original F
eed Unit
)
179
