5.System Maintenance
192
Test Pattern Printing
Printing Test pattern: SP2-109
Some of these test patterns are used for copy image adjustments but most are used primarily for design testing.
ï‚· Do not operate the machine until the test pattern is printed out completely. Otherwise, SC will occur.
1. Enter the SP mode.
2. Press SP2-109-001.
3. Select a test pattern from the list, and then press [OK].
4. To change the density of the test pattern, select the density with SP2-109-002, then press [#].
ï‚· If the value of SP2-109-002 is 0, the color adjusted so will not show up in the test pattern.
5. To print, press [Copy Window], and then make settings within the copy window for the test print (paper size etc…).
6. Press [Start] to start the test print.
7. After checking the test pattern, press [SP Mode] on the screen to return to the SP mode display.
8. Reset all settings to the default values with SP2-109-003 and SP2-109-006.
9. Exit SP mode.
