2.Installation
36
 Select "Interface Settings"> "Network" > "LAN Type". The "LAN Type" (default: Ethernet) must be
specified for either Ethernet or wireless LAN.
3. Select "Interface Settings"> "Wireless LAN".
Only the wireless LAN options are displayed.
4. Specify the "Communication Mode".
5. Enter the "SSID setting". (The setting is case sensitive.)
6. Specify the "Ad-hoc Channel". You need this setting when Ad Hoc Mode is selected. The allowed range for the
channel settings may vary for different countries.
 For mainly Europe and Asia
2412 - 2462 MHz (1 - 11 channels)
5180 - 5240 MHz (36, 40, 44 and 48 channels)
(default: 11)
 In some countries, only the following channels are available: 2412 - 2462 MHz (1 - 11 channels)
 For mainly North America
2412 - 2462 MHz (1 - 11 channels)
5180 - 5240 MHz (36, 40, 44 and 48 channels)
(default: 11)
7. Specify the "Security Method" for encryption of the Wireless LAN.
 The "WEP" (Wired Equivalent Privacy) setting is for protecting wireless data transmission. The same WEP key
is required on the receiving side in order to unlock encoded data. There are 64 bit and 128 bit WEP keys.
 Range of Allowed Settings:
64 bit: 10 characters
128 bit: 26 characters
 Specify "WPA2" when "Infrastructure Mode" is selected for "Communication Mode". Specify the "WPA2
Authent. Method".
 WPA2 Authent. Method:
Select either "WPA2-PSK" or "WPA2".
If you select "WPA2-PSK", enter the pre-shared key (PSK) of 8-63 characters in ASCII code.
When "WPA2" is selected, authentication settings and certificate installation settings are required.
8. Press "Wireless LAN Signal" to check the machine's radio wave status using the operation panel.
 Press "Restore Factory Defaults" to initialize the wireless LAN settings.
SP Mode Settings for IEEE 802.11 Wireless LAN
The following SP commands and UP modes can be specified for IEEE 802.11
SP No.
Name
Function
SP5-840-
Channel MAX
Specifies the maximum range of the channel settings for the country.
