Ricoh M0A0 User Manual

3.Appendices: SP Mode Tables
160
Input and Output Check
When entering the Input Check mode, 8 digits display the result for a section. Each digit corresponds to a different
device as shown in the table.
Bit No.
7
6
5
4
3
2
1
0
Result
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
0 or 1
Input Check Table
SP No.
Large Category
Small Category
ENG or CTL
[Min to Max/Init./Step]
5-803-001
INPUT Check
Paper Size
ENG
[0 to 15/0/1]
5-803-002
INPUT Check
Paper End
ENG
[0 to 1/0/1]
5-803-003
INPUT Check
Bypass:Paper End
ENG
[0 to 1/0/1]
5-803-004
INPUT Check
Bypass:Tray
ENG
[0 to 1/0/1]
5-803-005
INPUT Check
Paper Exit Full
ENG
[0 to 1/0/1]
5-803-006
INPUT Check
Paper Exit
ENG
[0 to 1/0/1]
5-803-008
INPUT Check
Registration
ENG
[0 to 1/0/1]
5-803-010
INPUT Check
Duplex:Entrance
ENG
[0 to 1/0/1]
5-803-011
INPUT Check
Duplex:Reverse
ENG
[0 to 1/0/1]
5-803-012
INPUT Check
Rear Interlock
ENG
[0 to 1/0/1]
5-803-013
INPUT Check
Front Interlock
ENG
[0 to 1/0/1]
5-803-017
INPUT Check
Fusing Unit New
ENG
[0 to 1/0/1]
5-803-018
INPUT Check
Fusing Unit Set
ENG
[0 to 1/0/1]
5-803-019
INPUT Check
HVP: SC_C_DV
ENG
[0 to 1/0/1]
5-803-020
INPUT Check
HVP: SC_T
ENG
[0 to 1/0/1]
5-803-022
INPUT Check
PSU Fan Lock
ENG
[0 to 1/0/1]
5-803-023
INPUT Check
Fusing Fan Lock
ENG
[0 to 1/0/1]
5-803-024
INPUT Check
Drum Fan Lock
ENG
[0 to 1/0/1]
5-803-025
INPUT Check
Main Motor Lock
ENG
[0 to 1/0/1]
5-803-026
INPUT Check
Key Card Set
ENG
[0 to 1/0/1]
5-803-027
INPUT Check
BiCU Ver
ENG
[0 to 7/0/1]
5-803-028
INPUT Check
Key Counter Set1
ENG
[0 to 1/0/1]
5-803-029
INPUT Check
Key Counter Set2
ENG
[0 to 1/0/1]
5-803-083
INPUT Check
BANK1:500/250
ENG
[0 to 1/0/1]
5-803-084
INPUT Check
BANK2:500/250
ENG
[0 to 1/0/1]
5-803-087
INPUT Check
BANK1:Relay SN
ENG
[0 to 1/0/1]
5-803-088
INPUT Check
BANK2:Relay SN
ENG
[0 to 1/0/1]
5-803-092
INPUT Check
BANK1:Paper End
ENG
[0 to 1/0/1]
5-803-093
INPUT Check
BANK2:Paper End
ENG
[0 to 1/0/1]
