7.Detailed Descriptions
317
 After detaching the toner cartridge together with the PCDU, you can use the release lever to separate the PCDU
from the toner cartridge.
[A]: Locked, [B]: Unlocked
 The release lever works in two steps. To release the lock, push down the release lever to the horizontal
position.
Toner Cartridge
Overview
 The toner cartridge contains the toner box, toner supply mechanisms and the used toner collection box.
 The toner supply port on the toner cartridge has a shutter that opens when the toner cartridge is installed in the
PCDU.
Toner
One type only.
10,400 pages (6%, 3P/J)
Details
Toner Supply
The toner supply clutch turns ON and the coils in the toner cartridge rotate to transfer toner to the box tap and then the
PCDU. The toner transferred to the PCDU is transferred to the development unit by the 1st mixing coil.
