4.Replacement
and Adjust
ment
170
2.
Remove the S
PDF original set
sensor [A].
SPDF Registration Sensor
1.
Open the SPD
F [A].
2.
Remove the pl
ate [B] to r
emove the scanning g
uide plate
[C].
3.
Remove the S
P
DF r
egistration sensor wit
h bracket [A]
.
181
183
