Ricoh M0A0 - PCDU Cooling Fan

4.Replacement and Adjustment
161
 When you reattach the fusing fan, attach it correctly (as shown above, the face of the fan with the sticker
is on the outside).
PCDU Cooling Fan
1. Remove the upper cover. (Upper Cover)
2. Remove the BiCU. (BiCU)
3. Remove the PCDU cooling fan [A] with bracket. ( x2, x1)
4. Remove the PCDU cooling fan [A] from the bracket. ( x3)
