Ricoh M0A0 User Manual

2.Installation
38
IEEE 1284 Interface Board Type M19 (D3C0-17)
Accessories
No.
Description
Qty
1
IEEE 1284 Interface board
1
2
FCC document
1
3
Notes for Users
1
Installation procedure
 Before installing this option, turn OFF the main power and unplug the power cord from the wall socket.
Otherwise an electric shock or a malfunction may occur.
 Do not put your hand into the controller box. It will result in a malfunction or injury.
 Before doing any work, touch a metal object to discharge static electricity from your body. Static electricity
may cause the board to malfunction.
1. Remove the slot cover [A].
