2.Replacement and Adjustment
12
3. Detach the paper feed motor [B] from the bracket [A]. ( x2)
Paper End Sensor
1. Paper Feed Tray (Paper Feed Tray)
2. Bracket [A] ( x4)
3. Paper End Sensor [A] ( x1, Hook)
Paper Feed Sensor
1. Paper Feed Tray (Paper Feed Tray)
