Ricoh M0A0 - Registration Sensor

4.Replacement and Adjustment
144
2. Slide the registration roller (drive) [A] to the right to remove it.
Registration Sensor
1. Remove the PCDU. (PCDU)
2. Remove the sheet [A].
3. Release the hooks of the harness cover [A] with a screwdriver to remove it.
4. Remove the registration sensor [A]. (Hook, x1)
