2.Installation
16
2.
Ins
tallati
on
Inst
allation
Requi
re
men
ts
Envir
onment
1.
T
emp
eratur
e Range: 10°C to
32°C (50
°F to 89.6°F)
2.
Humidity Ran
ge: 15% to
80% RH
3.
Ambient
Illumination: Le
ss than 1,500 l
ux (do not expo
se to dir
ect sunlight)
4.
V
entilation: 3 times/hr/
person
5.
Do not install the m
achine at l
ocations over 2,
000 m (
6,562 ft.) above se
a level.
Machine Space Requir
ements
1
Rear
Over 20 cm (
7.9 inches)
27
29
