Ricoh M0A0 - G4 Internal Switches

4.Service Tables
83
G3-2 Switch 08 - Not used (do not change the settings)
G3-2 Switch 09 - Not used (do not change the settings)
G3-2 Switch 0A (SP No. 1-106-011)
No
Function
Comments
0-
1
Maximum allowable
carrier drop during image
data reception
These bits set the acceptable modem carrier drop time.
Try a longer setting if error code 0-22 is frequent.
Bit 1
Bit 0
Value (ms)
0
0
200
0
1
400
1
0
800
1
1
Not used
2-
3
Not used
Do not change the settings
4
Maximum allowable
frame interval during
image data reception.
0: 5 s 1: 13 s
This bit set the maximum interval between EOL (end-of-line) signals and the
maximum interval between ECM frames from the other end.
Try using a longer setting if error code 0-21 is frequent.
5
Not used
Do not change the settings.
6
Reconstruction time for the
first line in receive mode
0: 6 s 1: 12 s
When the sending terminal is controlled by a computer, there may be a delay in
receiving page data after the local machine accepts set-up data and sends CFR.
This is outside the T.30 recommendation. But, if this delay occurs, set this bit to 1
to give the sending machine more time to send data.
Refer to error code 0-20.
ITU-T T.30 recommendation: The first line should come within 5 s of CFR.
7
Not used
Do not change the settings.
G3-2 Switch 0B- Not used (do not change the settings)
G3-2 Switch 0C- Not used (do not change the settings)
G3-2 Switch 0E- Not used (do not change the settings)
G3-2 Switch 0F- Not used (do not change the settings)
G4 Internal Switches
The G4 internal switches (SW00 to 1F) are displayed but do not change these settings.
