Ricoh M0A0 - Page 708

4.Service Tables
82
Cross reference
V.8 protocol on/off - G3 switch 03, bit 2
Bit 7
Bit 6
Bit
5
Bit
4
Types
0
0
0
1
V.27ter
0
0
1
0
V.27ter
0
0
1
1
V.27ter
0
1
0
0
V.27ter
0
1
0
1
V.27ter
Other settings - Not used
G3-2 Switch 07 (SP No. 1-106-008)
No
Function
Comments
0-
1
PSTN cable equalizer
(TX mode: Internal)
Use a higher setting if there is signal loss at higher frequencies because of the length
of wire between the modem and the telephone exchange.
Use the dedicated transmission parameters for specific receivers.
Also, try using the cable equalizer if one or more of the following symptoms occurs.
Communication error
Modem rate fallback occurs frequently.
 This setting is not effective in V.34 communications.
Bit
1
Bit
0
Setting
0
0
None
0
1
Low
1
0
Medium
1
1
High
2-
3
PSTN cable equalizer
(RX mode: Internal)
Use a higher setting if there is signal loss at higher frequencies because of the length
of wire between the modem and the telephone exchange.
Also, try using the cable equalizer if one or more of the following symptoms occurs.
Communication error with error codes such as 0-20, 0-23, etc.
Modem rate fallback occurs frequently.
 This setting is not effective in V.34 communications.
Bit
3
Bit
2
Setting
0
0
None
0
1
Low
1
0
Medium
1
1
High
4
PSTN cable equalizer
(V.8/V.17 RX mode:
External)
0: Disabled
1: Enabled
Keep this bit at "1".
5-
7
Not used
Do not change the settings.
