4.Replacement and Adjustment
171
4. Remove the registration sensor [A] from the bracket.
DFRB
1. Remove the SPDF rear cover. (SPDF Rear Cover)
2. Remove the DFRB [A].
SPDF Feed Clutch
1. Remove the front cover. (SPDF Front Cover)
