4.Replacement
and Adjust
ment
121
3.
Remove the h
arness guide [
A].
4.
Remove the pa
per feed clut
ch [A].
Drive Unit
1.
Remove the BiC
U. (
BiCU
)
2.
Remove the du
plex clutch. (
Duple
x Clutch
)
3.
Remove the d
rive unit [A].
