4.Replacement and Adjustment
123
2. Remove the harness guide [A]. ( x1, x1)
3. Remove the bypass feed clutch [A]. ( x1, x1)
Relay Clutch
1. Remove the bypass feed unit. (Bypass Feed Unit)
2. Remove the gear unit. (Gear Unit)
3. Remove the relay clutch [A].
Bypass Bottom Plate Clutch
1. Remove the right cover. (Right Cover)
