5.System Maintenance
207
5. Turn ON the main power.
6. Execute SP5-824-001 (NVRAM Data Upload) and then press the “Execute” key.
7. The following files are copied to an NVRAM folder on the SD card when the upload procedure is finished.
The file is saved to the path and the following filename:
NVRAM\<serial number>.NV
Here is an example with Serial Number “K5000017114”:
NVRAM\K5000017114.NV
8. In order to prevent an error during the download, be sure to mark the SD card that holds the uploaded data with
the number of the machine from which the data was uploaded.
You can upload NVRAM data from more than one machine to the same SD card.
Downloading an SD Card to NVRAM
Do the following procedure to download SP data from an SD card to the NVRAM in the machine.
The NVRAM data download may fail if the SD card with the NVRAM data is damaged, or if the connection
between the controller and BiCU is defective.
Do the download procedure again if the download fails.
Do the following procedure if the second attempt fails:
Enter the NVRAM data manually using the SMC print you created before uploading the NVRAM data.
1. Turn OFF the main power.
2. Remove the SD card slot cover.
3. Insert the SD card with the NVRAM data into SD slot 2.
4. Turn ON the main power.
5. Do SP5-825-001 (NVRAM Data Download) and press the “Execute” key.
The serial number of the file on the SD card must match the serial number of the machine for the
NVRAM data to download successfully. The download fails if the serial numbers do not match.
This procedure does not download the following data to the NVRAM:
Total Count
C/O, P/O Count
