Ricoh M0A0 - Bypass Friction Pad

4.Replacement and Adjustment
137
6. Separate the bypass feed roller [A] from the shaft (Hook x1)
Bypass Friction Pad
1. Remove the bypass feed unit. (Bypass Feed Unit)
2. Remove the bottom plate [A].
 If you cannot remove the bottom plate because the part [A] prevents the cam [B] from releasing, rotate
the shaft [C] to move the cam [B] away from the bottom plate link [A].
