4.Replacement and Adjustment
136
3. Remove the x2, Bearing x2 on both sides of the bypass feed roller (guide) [A].
4. Slide the bypass feed guide [A] with the bypass feed roller to the right to detach it from the machine.
5. Detach the bypass feed roller with the shaft [B] from the guide [A].
