3.Troubleshooting
32
Check Point
Action
Raise the delay level.
IPFAX SW 01 Bit 0 to 3
Lower the modem transmission baud rate.
IPFAX SW 05
16
Remote fax cancelled transmission?
Check whether the remote fax cancelled the
transmission.
IP-Fax Reception
Cannot receive via IP Address/Host Name
Check Point
Action
1
LAN cable connected?
Check the LAN cable connection.
2
Firewall/NAT is installed?
Cannot breach the firewall. Send by using another method
(Fax, Internet Fax)
3
IP address of local fax registered?
Register the IP address.
4
Port number specified at remote sender fax (if
required)?
Request the sender to specify the port number.
5
Specified port number correct (if required)?
Request the sender to check the port number.
6
DNS server registered when host name
specified on sender side?
Contact the network administrator.
 The sender machine displays this error code if the
sender fax is a Ricoh model.
7
Network bandwidth too narrow?
Request the system administrator to increase the bandwidth.
Lower the start modem reception baud rate on the receiving
side.
IPFAX SW06
8
Remote fax cancelled transmission?
Check whether the remote fax cancelled the transmission.
Cannot receive by VoIP Gateway
Check Point
Action
1
LAN cable connected?
Check the LAN cable connection.
2
Firewall/NAT is installed?
Cannot breach the firewall. Request the remote fax to send by
using another method (Fax, Internet Fax)
3
VoIP Gateway installed correctly?
Contact the network administrator.
4
VoIP Gateway power switched on?
Contact the network administrator.
5
IP address/host name of specified VoIP
Gateway correct on sender’s side?
Request the remote fax to check the IP address/host name.
