4.Replacement and Adjustment
156
2. Remove the BiCU [A].
3. Remove the EEPROM [A] from the old board and install it on the new board.
Install so that the indentation [B] on EEPROM is facing the direction of the dent [C] that is printed on the BiCU
board.
4. Install the new BiCU in the machine.
5. Enter the BiCU serial number.
ï‚· If the BiCU serial number is not entered correctly, SC995-01 (serial number entry error) will occur.
6. Turn the main power OFF then ON.
7. Set the DIP switches on the new BiCU board to the same settings as the old board.
ï‚· Make sure the EEPROM is correctly installed on the BiCU. Insert the EEPROM in the EEPROM slot with the
"half-moon" pointing [C] to the downside.
EEPROM on the BiCU
Keep EEPROMs away from any objects that can cause static electricity. Static electricity can damage EEPROM data.
1. Make sure that you have the SMC report (factory settings). This report comes with the machine.
