4.Replacement and Adjustment
118
Drive Units
 Turn OFF the main power and disconnect the power cord before you start any of the procedures in this
section.
Main Motor
1. Remove the right cover. (Right Cover)
2. Remove the drive unit. (Drive Unit)
3. Remove the main motor [A].
Duplex Exit Motor
1. Remove the upper cover. (Upper Cover)
2. Remove the duplex exit motor [A].
Toner Supply Clutch
1. Remove the gear unit (Gear Unit)
