2.Installation
80
6. Enter the SP mode.
7. Select SP5-873-001 "Move Exec".
8. Follow the messages shown on the operation panel.
9. Turn the main power OFF.
10. Remove the source SD card from SD Card Slot 2 [B].
11. Attach the SD card slot cover.
12. Turn the main power ON.
13. Check that the application programs run normally.
Undo Exec
"Undo Exec" (SP5-873-002) lets you move application programs from an SD card in SD Card Slot 1 (upper) back to
the original SD card in SD Card Slot 2 (lower). You can use this program when, for example, you have mistakenly
copied some programs by using Move Exec (SP5-873-001).
ï‚· Do not turn ON the write protect switch of the system SD card or application SD card on the machine. If the
write protect switch is ON, a download error (e.g. Error Code 44) will occur during a firmware upgrade or
application merge.
1. Turn the main power OFF.
2. Remove the SD card slot cover [A].
To Next Page
