7.Detailed
Descriptions
313
1.
Sheet
2.
Base
3.
L
ED Boar
d
4.
Frame
5.
SLA (SELFOC LENS
ARRA
Y)
Mechanisms
W
riting meth
od
Tiny LEDs
capable of cr
eating images at 12
00
dpi ar
e arranged in
a line. Light
beams emitt
ed by the LEDs
are f
ocused
using the Self
-focusing Lens
Array (SLA)
, creat
ing an image
on the OPC
drum.
1.
LED Boar
d
2.
SLA (SELFOC
LENS ARRA
Y)
3.
OPC
324
326
