Ricoh M0A0 - Image Transfer; Image Transfer Roller

4.Replacement and Adjustment
117
Image Transfer
Image Transfer Roller
1. Remove the PCDU. (PCDU)
2. Pinch both green ends of the guide [A] and pull it towards you.
3. Remove the image transfer roller [A].
