5.System Maintenance
211
SP Data Import/Export
Data that can be imported and exported
System SP
Printer SP
Fax SP
Scanner SP
Exporting Device Information
When exporting SP device information from the control panel, the data is saved on an SD card.
1. Insert an SD card into the media slot on the side of the control panel.
2. Enter SP mode.
3. Press SP5-749-001 (Import/Export: Export)
4. Select “Target” SP settings (System/Printer/Fax/Scanner) to be exported.
5. Select “Option” settings (Unique/Secret).
Unique information of the machine is
included in the exported file if you select
"Unique" setting.
Unique information that can be updated
#1. Items that are to be used to identify the machine.
Example: Network Information/ Host name /
Information related to fax number /Mail address
assigned to the machine
#2. Items for specifying the options equipped on the
machine.
Example: Lot number for developer
Unique information that cannot be updated
#1. Items that may cause a problem if imported
Example: Serial number / Information related to
@Remote
#2. Items for managing the history of the machine
Example: Time and date / Counter information /
Installation date
#3. Setting values for the Engine
Secret information is exported if you select
"Secret" setting.
#1. Data that cannot be exported without being
encrypted.
(Exported data is encrypted.)
Example: Password / Encryption key / PIN code
#2. Confidential information for the customer
Example: User name / User ID / Department code /
To Next Page
