7.Detailed
Descriptions
328
1.
SW1
2.
SW2
3.
SW3
Pap
er size
de
tection
co
mb
ination
(L:
Swi
tch i
s pr
esse
d)
SW 1
SW 2
SW 3
Paper Size
1
L
L
L
A4 SEF
2
L
H
L
A5 SEF
3
H
L
L
A6 LEF
4
H
H
L
LegalSEF
5
L
L
H
Letter SEF
6
L
H
H
-
7
H
L
H
HalfLetter_SE
F
8
H
H
H
Paper cas
sette is not set.
339
341
