1.Replacement and Adjustment
12
LCD
1. Operation panel unit (Operation Panel Unit)
2. CPU board (CPU Board)
3. Micro computer board (Micro Computer Board)
4. Speaker [A] ( ×2)
5. Lift the fastener of the LCD I/F cable.
