2.Mechanism
27
No.
Name
Description
1
Speaker
There is currently no function that uses this.
2
Display panel
Displays icons for functions and applications. Displays the operation screens,
operation keys and other information.
3
Main power indicator
Indicates power OFF/ON status.
4
USB slot for digital
cameras
A digital camera can be connected here.
5
USB slot for NFC card
readers
A near field communication (NFC) device can be connected here.
6
Microphone
There is currently no function that uses this.
7
[Check Status] indicator
Indicates system status.
8
Data In indicator
Flashes when the machine receives data from a printer driver or LAN-Fax driver.
9
Fax indicator
Indicates fax status.
ï‚· During communication: Flashes
ï‚· When fax documents have been received using Substitute Reception: Lights
ï‚· When the machine has received a confidential fax document: Lights
10
Extended Feature key
(EX3)
Used for system maintenance, such as control panel self-check.
11
Extended Feature key
(EX2)
Used for system maintenance, such as control panel self-check.
12
Extended Feature key
(EX1)
Used for system maintenance, such as control panel self-check.
13
Control panel reboot
key
Used when rebooting the control panel.
14
SD card slot
Insert an SD card here.
15
Media access lamp
Lights when an external media is inserted into the SD card slot or the USB slot.
16
USB slot
Insert a USB memory device here.
Panel display
Screen Layout
