Page #724 background imageLoading...
Page #724 background image
4.Service Tables
98
Address
Function
Unit
Remarks
6805AF
Acceptable AI short protocol tone
(800Hz) detection frequency upper limit
(high byte)
Hz (BCD)
If both addresses contain FF (H), tone
detection is disabled.
6805B0
Acceptable AI short protocol tone
(800Hz) detection frequency upper limit
(low byte)
6805B1
Acceptable AI short protocol tone
(800Hz) detection frequency lower limit
(high byte)
Hz(BCD)
If both addresses contain FF (H), tone
detection is disabled.
6805B2
Acceptable AI short protocol tone
(800Hz) detection frequency lower limit
(low byte)
6805B3
Detection time for 800 Hz AI short
protocol tone
20 ms
Factory setting: 360 ms
6805B4
PSTN: Tx level from the modem
-N 3
dBm
SP2-103-002 (parameter 01).
6805B5
PSTN: 1100 Hz tone transmission level
- N 6805B4 - 0.5N 6805B5 3.5 (dB)
See Note 7.
6805B6
PSTN: 2100 Hz tone transmission level
- N6805B4 - 0.5N 6805B6 3 (dB)
See Note 7.
6805B7
PABX: Tx level from the modem
- dBm
6805B8
PABX: 1100 Hz tone transmission level
- N 6805B7 - 0.5N 6805B8 (dB)
6805B9
PABX: 2100 Hz tone transmission
level
- N 6805B7 - 0.5N 6805B9 (dB)
6805BD
Modem turn-on level (incoming signal
detection level)
-37-0.5N
(dBm)
6805BE to
6805C6
Not used
-
Do not change the settings.
6805C7
Bits 0 to 3 Not used
Bit 4 = V.34 protocol dump 0: Simple, 1: Detailed (default)
Bits 5 to 7 Not used.
6805C8 to
6805D9
Not used
-
Do not change the settings.
6805DA
T.30 T1 timer
1 s
6805E0
bit 3
Maximum wait time for post message
0: 12 s
1: 30 s
1: Maximum wait time for post message
(EOP/EOM/MPS) can be changed to 30 s.
Change this bit to “1” if communication
