Popup Menu Setup CMU
1100.4903.12 4.14 E-10
Software
Options
The Software Options section contains a list of all software options for the CMU.
The check boxes behind each software option determine the system configuration:
Enable Enable (box checked) or disable software option. Options
purchased with a new unit are already enabled. Software options
purchased later must be explicitly enabled with a key code to be
functional; see below.
Ch1 active Ch2 Activate (box checked) or deactivate software option on the next
reboot. After deactivating an option by unchecking one of the
boxes, the CMU displays the following message:
Deactivating software options that are temporarily not needed
improves the system performance, especially during the start-up
process when all active firmware options must be loaded. An
enabled but deactivated option can be re-activated any time
without any key code or other additional input.
Note: Some options, e.g. options CMU-K39 to CMU-K43, are supplementary
options extending the GSM-BTS and GSM-MS options. The
supplementary options must be enabled with a key code but can not
be deactivated. No Ch1 active Ch2 boxes are provided.
Enabled options are active by default. Disabled options are inactive
and can not be activated.
Remote control
SYSTem:OPTions?
*OPT?
Enabling
software options
Software options can be enabled or disabled in the Enable check boxes of the
Software Options table. As all software options are already included in the
firmware, enabling does not require any re-installation, but only a key code which is
supplied with the option.
! Select the respective line in the list of software options (in the example of Fig. 4-
9 the line CMU-K20 GSM400-MS),
! Press the Enter key.
The popup window Option Enable appears on the screen:
The Option Enable window contains the following fields:
Option Short designation and name of option
CMU Serial Number Serial number of the CMU basic instrument
