Rohde & Schwarz CMU 200 User Manual

Audio Generator and Analyzer (with Option CMU-B41) CMU
1100.4903.12 6.84 E-10
CONFigure:MULTitone:AF1Channel:FILTer:BPASs:DCCoupling Band Pass, DC Coupling
CONFigure:MULTitone:AF2Channel:FILTer:BPASs:DCCoupling
<Bandpass>
<Bandpass>
Description of parameters Def. value Def. unit FW vers.
BP02 |
BP03 |
BP05 |
BP06 |
BP07 |
BP09 |
BP10 |
BP11 |
BP13 |
BP14 |
BP15 |
BP17 |
BP18
CMU band pass filter with a bandwidth of
6 Hz to 250 Hz
50 Hz to 250 Hz
6 Hz to 3000 Hz
50 Hz to 3000 Hz
300 Hz to 3000 Hz
6 Hz to 4000 Hz
50 Hz to 4000 Hz
300 Hz to 4000 Hz
6 Hz to 15000 Hz
50 Hz to 15000 Hz
300 Hz to 15000 Hz
6 Hz to 21000 Hz
50 Hz to 21000 Hz
BP17 – V3.0
Description of command
This command selects the band pass filter to be used if the AF path coupling is set to DC (see CONFig-
ure:AFANalyzer[:PRIMary]:COUPling command).
CONFigure:MULTitone:AF1Channel:FILTer:BPASs:ACCoupling Band Pass, AC Coupling
CONFigure:MULTitone:AF2Channel:FILTer:BPASs:ACCoupling
<Bandpass>
<Bandpass>
Description of parameters Def. value Def. unit FW vers.
BP01 |
BP02 |
BP03 |
BP04 |
BP05 |
BP06 |
BP07 |
BP08 |
BP09 |
BP10 |
BP11 |
BP12 |
BP13 |
BP14 |
BP15 |
BP16 |
BP17 |
BP 18
CMU band pass filter with a bandwidth of
0 Hz to 250 Hz
6 Hz to 250 Hz
50 Hz to 250 Hz
0 Hz to 3000 Hz
6 Hz to 3000 Hz
50 Hz to 3000 Hz
300 Hz to 3000 Hz
0 Hz to 4000 Hz
6 Hz to 4000 Hz
50 Hz to 4000 Hz
300 Hz to 4000 Hz
0 Hz to 15000 Hz
6 Hz to 15000 Hz
50 Hz to 15000 Hz
300 Hz to 15000 Hz
0 Hz to 21000 Hz
6 Hz to 21000 Hz
50 Hz to 21000 Hz
BP16 – V3.0
Description of command
This command selects the band pass filter to be used if the AF path coupling is set to AC (see CONFig-
ure:AFANalyzer[:PRIMary]:COUPling command).
