Service Manual Modules
The service manual modules is not delivered with the instrument but may be obtained from your
R&S service department using the order number 1100.4903.91.
Service manual modules contains information about the individual modules of CMU. This comprises
the test and adjustment of the modules, fault detection within the modules and the interface descrip-
tion.
Operating Manuals for Digital and Analog Network Tests
The operating manuals listed in the following table describe the test of mobile phones supporting dif-
ferent standards by means of the CMU200/CMU300 and the appropriate software and hardware op-
tions. Except for hardware-specific chapters that are not relevant to the software options, the net-
work test operating manuals are organized like the present CMU operating manual.
For Options
Manual Order Number Type Description Stock No.
Operating Manual
CMU-K20/-K21/-
K22/-K23/-K24
1115.6088.12 CMU-K20
CMU-K21
CMU-K22
CMU-K23
CMU-K24
CMU-K42
CMU-K43
CMU-K45
GSM400-MS for CMU-B21
GSM900-MS for CMU-B21
GSM1800-MS for CMU-B21
GSM1900-MS for CMU-B21
GSM850-MS for CMU-B21
GPRS software extension for GSM
EGPRS software extension for GSM
AMR GSM for CMU200
1115.5900.02
1115.6007.02
1115.6107.02
1115.6207.02
1115.6307.02
1115.4691.02
1115.6907.02
1150.3100.02
Operating Manual
CMU-K27/-K28
1115.6688.12 CMU-K27
CMU-K28
TDMA800-MS for CMU-B21
TDMA1900-MS for CMU-B21
1115.6607.02
1115.6707.02
Operating Manual
CMU-K29
1115.6888.12 CMU-K29 AMPS-MS for CMU-B21 1115.6807.02
Operating Manual
CMU-K30/-K31/-
K32/-K33
1115.4185.12 CMU-K30
CMU-K31
CMU-K32
CMU-K33
CMU-K39
CMU-K41
GSM400-BS for CMU-B21
GSM900-BS for CMU-B21
GSM1800-BS for CMU-B21
GSM1900-BS for CMU-B21
MOC/MTC
EDGE for CMU-K30/31/32/33
1115.4004.02
1115.4104.02
1115.4104.02
1115.4104.02
1115.4791.02
1115.4604.02
Operating Manual
CMU-K53
1115.5081.12 CMU-K53 Bluetooth for CMU 1115.5000.02
Operating Manual
CMU-K65/…/-K69
1115.4962.12 CMU-K65
CMU-K66
CMU-K67
CMU-K68
CMU-K69
WCDMA UE TX Test (3GPP/FDD)
WCDMA UE DL Generator
WCDMA UE Band III Signalling
WCDMA UE Band I Signalling
WCDMA UE Band II Signalling
1115.4891.02
1115.5100.02
1150.3000.02
1115.5300.02
1115.5400.02
Operating Manual
CMU-K75/-K76
1150.3398.12 CMU-K75
CMU-K76
WCDMA Node B TX Tests
WCDMA Generator (3GPP/FDD,
Release 99, Uplink)
1150.3200.02
1150.3300.02
Operating Manual
CMU-K81/-K82
1115.5581.12 CMU-K81
CMU-K82
CDMA800-MS (IS95) for CMU-B81
CDMA1900-MS (IS95) for CMU-B81
1115.5500.02
1115.5600.02
Operating Manual
CMU-K83/-K84/
-K85/-K86
1150.0382.12 CMU-K83
CMU-K84
CMU-K85
CMU-K86
CDMA2000-MS (450 MHz band)
CDMA2000-MS (cellular band)
CDMA2000-MS (PCS band)
CDMA2000-MS (IMT-2000 band)
1150.3500.02
1150.3600.02
1150.3700.02
1150.3800.02
The GSM base station tests described in operating manual CMU-K30/-K31/-K32/-K33/-K34 and the
WCDMA UL generator described in operating manual CMU-K75/-K76 require a CMU300 (Universal
Radio Communication Tester for BTS). Bluetooth tests are performed with model CMU200, var. 53.
All other radio communication equipment is tested with model CMU200, var.02.
To Next Page
