Installation & Configuration Manual
i.e. Open once to SET the system, Close and Open again to
UNSET)
If the ‘Fullset Enable’ attribute is set then zone activation will only
Fullset the system.
If the ‘Unset Enable’ attribute is set then zone activation will only
unset the system.
Keyarming will force set the system/area and auto-inhibit any open
zones or fault conditions.
Note: Your system will not comply with EN standards if you enable this
zone type to set the system without first entering a valid PIN on an
external device.
This zone type is only available in Commercial Mode of operation.
Though the Shunt Alarm Zone type can be set in Domestic Mode of
operation, it has no effect.
This zone type when opened inhibits all zones that have the shunt
attribute set. This operation applies for both SET and UNSET modes. As
soon as the shunt zone is closed, the zones with the shunt attribute set
will become un-inhibited again.
This zone type is only available in Commercial Mode of operation.
A zone programmed with the x-shunt zone type inhibits the next
consecutive zone on the system whenever it is opened. This operation
applies for both SET and UNSET modes. As soon as the x-shunt zone
type is closed the next zone becomes de-inhibited again.
Detector Fault zones are 24 hour zones that are applicable to a detector
device, for example, a PIR. The fault zone type triggers the Fault output.
When the system is armed, a fault output is triggered. Both the keypad
LED and the buzzer are activated when Unarmed.
Only available in Commercial mode.
Used to monitor a door lock. System can be programmed not to set
unless door is locked.
Only available if the panel is in Financial mode of operation. Vibration
sensors, also called seismic sensors, are used to detect intrusion
attempts by mechanical means, such as drilling or making holes through
walls or safes.
This zone type enables a special entry procedure to be implemented
using a user code and ‘All Okay’ input. A silent alarm is generated if an
All Okay button is not pressed within a configurable time after a user
code is entered. (See Areas [➙ 238] for details of ‘All Okay’
configuration)
All Okay uses two outputs, Entry Status (Green LED) and Warning
Status (Red LED), to indicate entry status using LEDs on the keypad.
Allows a zone to be disabled without the need for each zone to have
EOL resistors fitted. Any activation on the zone will be ignored.
Holdup Fault zones are 24 hour zones that are applicable to a holdup
signaling device, for example, a WPA. The fault zone type triggers the
Fault output.
When the system is armed, a fault output is triggered. Both the keypad
LED and the buzzer are activated when Unarmed.
This zone type will report the SIA messages, HT (Holdup Trouble) and
HJ (Holdup Trouble Restore) and for CID, a sensor trouble event (380) is
produced.
Warning Fault zones are 24 hour zones that are applicable to a warning
signaling device, for example, an internal or external bell. The fault zone
type triggers the Fault output.
When the system is armed, a fault output is triggered. Both the keypad
LED and the buzzer are activated when Unarmed.
This zone type will report the SIA messages, YA (Bell Fault) and YH (Bell
Restore) and for CID, a sensor trouble event (380) is produced.
Note: On a grade 2 system, a cable fault will cause a fault and not an
