Engineer programming via the keypad
Installation & Configuration Manual
Before changing PIN or new SIM card, ensure all power sources are
disconnected (AC mains and battery) or card will not be activated.
After a factory default, during the process of initial setup of the system with the
keypad, the panel detects if it has a primary or backup modem fitted, and if so, it
displays its type and automatically enables it (or them) with the default
configuration. No other modem configuration is allowed at this stage.
16.11.3.2 Configuring Modems
To configure a GSM or PSTN modem:
1. Scroll to MODEMS and press SELECT.
2. Toggle between PRIMARY and BACKUP for correct modem slot and press
SELECT.
The ENABLE MODEM option is displayed.
3. ENABLE or DISABLE the modem as required.
4. Scroll to MODEM STATUS, TYPE, FIRMWARE VERSION and SIGNAL
LEVEL and press SELECT to view details of the modem.
5. Configure the following modem settings from the menu as follows and press
ENTER after each selection:
Select a country from the list.
(GSM modem only) Enter a GSM PIN for the SIM card.
Select to select the mode in which the modem answers
incoming calls: NEVER ANSWERS or ALWAYS
ANSWERS
Select ENABLE to only answer when engineer access is
granted.
Select ENABLE SMS to enable SMS for this modem.
(Only for PSTN.) Select SMS SERVER to enter an
appropriate phone number of the SMS service provider that
is accessible in your location, if required. This number
automatically displays the default number for SMS for the
country selected.
To manually test SMS, select TEST SMS and enter the
SMS NUMBER.
To automatically test SMS at specific time intervals, select
AUTOMATIC TEST , select a TEST INTERVAL and enter
the SMS NUMBER.
(PSTN modem only) Enter a prefix number to include
before the SMS number, if required.
For PSTN: Enable this feature to monitor the voltage of the
line connected to the modem.
