Mounting system equipment
Installation & Configuration Manual
The battery flaps should be bent carefully as not to damage the battery. If any
signs of a damaged battery exist or any leakage of the electrolyte then the battery
should be discarded as per the current regulations and a new battery fitted.
6.3 Mounting a G5 housing
The SPC G5 housing comprises of a metallic base and front cover. The cover is
attached to the base of the housing by 4 securing screws located on the top and
bottom of the front cover.
To open the housing, remove all the screws with the appropriate screwdriver and
lift the cover directly from the base.
The G5 housing contains the controller PCB (Printed Circuit Board) and the
SPCP355.300 Smart PSU, both mounted on 4 support pillars. An 8 In/2 Output
Expander is mounted on top of the PSU. Four extra pillars are included to give you
the option to mount the 8 In/2 Output Expander below the PSU board in the G5
cabinet. Additional expanders can be installed in the housing as shown.
