Installation & Configuration Manual
It is recommended that the enclosed PD 6662:2010 label is affixed in an
appropriate position on the inside of the SPC housing beside the product type
label.
3.1.5.6 Additional information
Transmission Network Requirements – Performance, Availability and
Security Levels (BS EN 50136-1-2, 1998 and BS EN 50136-1-5,
2008)
The SPC System has been tested and approved to EN50136-1-1.
SPC levels are classified as follows:
Transmission time, max.
values
Refer to the following section in this manual:
ATS levels and attenuation specifications [➙ 354]
Signalling security level
Tested to EN50136-1-1 and classified as ‘S0’.
3.1.6 Compliance with VdS approvals
This installation document encompasses the required product installation
information for VdS approvals.
Vanderbilt
SPC42xx/43xx/53xx/63xx : VdS Approval Nr. G 112104, G112124, and G112128.
VdS EN Certificates EN-ST000142, EN-ST000143, EN-ST000055, EN-ST000056,
EN-ST000057, EN-ST000058, EN-ST000061, EN-ST000062.
Siemens
SPC42xx/43xx/53xx/: VdS Approval Nr. G116035. VdS EN Certificates EN-
ST000225, EN-ST000226, EN-ST000227, EN-ST000228, EN-ST000229, EN-
ST000230, EN-ST000231, EN-ST000232.
This section describes the compliance of this system with VdS approvals.
Software
To set the system for VDS compliance, do the following:
1. Log on to the panel with the browser.
2. Click Full Engineer.
3. Click Settings on the menu.
4. Click Standards.
5. Select the German region from the Region list.
6. Select the VDS grade required by your installation type.
Remote Isolations — It is not possible to deisolate isolated faults using the
browser or SPCPro. Deisolation can only be performed on the keypads.
Remote Connections — it is not possible to use the browser or SPCPro to
connect to an armed system.
Confirmed alarms — an internally set system cannot create a confirmed alarm.
