Page #136 background image
16
Engineer programming via the keypad
Outputs
136
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Attribute
Description
Door Sounder
Door controller PCB mounted sounder sounds on
door alarms.
Ignore Forced
Door forced open is not processed.
Interlock* (Browser)
Limit Interlocked Door Access
(SPCPro)
Only one door in an area will be allowed open at a
time. Requires Door Group.
Setting Prefix
Authorisation with prefix (A,B,* or #) key to set system
* Require door group
Door timers
Timer
Min.
Max.
Description
Access granted
1 s
255 s
The time the lock will remain open
after granting access.
Access deny
1 s
255 s
The duration after which the
controller will be ready to read the
next event after a invalid event.
Door open
1 s
255 s
Duration within which the door
must be closed to prevent a “door
open too long” alarm.
Door left open
1 min
180 min
Duration within which the door
must be closed to prevent a “door
left open” alarm.
Extended
1 s
255 s
Additional time after granting
access to a card with extended
time attribute.
Escort
1 s
30 s
Time period after presenting a card
with escort attribute within a user
without escort right can access the
door.
16.10 Outputs
Each zone type on the SPC system has an associated output type (an internal flag
or indicator). When a zone type is activated, i.e. a door or window opens, smoke is
detected, an alarm is detected, etc., the corresponding output is activated.
1. Scroll to OUTPUTS and press SELECT.
2. Scroll to CONTROLLER or EXPANDER and press SELECT.
3. Scroll to the expander/output to be programmed and press SELECT.
If the output activations are recorded in the system event log (i.e. enabled,
items recorded / disabled, items) the programming options are available as
shown in the table below.
NAMES
Used to help identify the output; enter a specific and descriptive name.
OUTPUT
TYPE
Determines the output type; see the table in page [➙ 137], for a description of output
types.
OUTPUT
MODE
Determines the style of the output: continuous, momentary or pulsed.
POLARITY
Determines whether the output is activated on a positive or negative polarity.
LOG
Determines if system log is enabled or disabled.
