Engineer programming via the keypad
Installation & Configuration Manual
Range is 0 – 7 (Max volume)
Select speaker volume for chime or disable sound.
Range is 0 – 7 (Max volume)
Select if the keypad should be limited by calendar. See Calendar.
Select if keypad should be limited by a mapping gate.
Select if keypad should be limited by a keyswitch.
Tick this box to disable the keys on the keypad during the entry time
when a PACE is configured on the keypad.
Select the secured area where the keypad is located.
Select which areas can be controlled through keypad.
Select to configure a delayed set across all keypads. The location of
the keypad is ignored and all areas will perform a full exit time count
down.
An area should be assigned to a keypad only if the keypad is inside the assigned
area, and if an entry/exit route is defined. If an area is assigned, when the
particular area is set or unset then entry and exit timers are used (if configured).
Other features related to entry/exit routes also become available. If no area is
assigned, the area is set or unset immediately and other entry/exit features are
not available.
16.6.4.4 Edit Expanders
To edit expanders:
1. Scroll to EXPANDERS > EDIT.
2. Press SELECT.
3. Scroll to the device to be edited and press SELECT.
Parameters and details, if applicable, are displayed for editing.
4. Press BACK to exit the menu.
For naming and identifying, expanders are allocated zones (in groupings of 8)
with subsequent identities of 1 to 512. (The greatest number in zone identification
is 512.) Therefore, any expander named or identified by a number greater than 63
has no allocated zones.
