Smart PSU
SPCP355.300 Smart PSU
64
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
To comply with NF & A2P installation regulations, this enclosure must be sealed
by affixing the accompanying Tamper Label after installation.
SPC products listed have been tested according to NF324 - H58, with reference to
RTC50131-6 and RTC50131-3 and current EN certifications, see Compliance with
EN50131 Approvals [➙ 19].
Product Type
Configuration
Standard
Logo
SPC6350.320 +
SPCP355.300
(Cert. XXXXXXXXXX)
60h, unmonitored
NF Grade 3,
Class 1
SPC5350.320 +
SPCP355.300
(Cert. XXXXXXXXXX)
60h, unmonitored
SPC6330.320 +
SPCP333.300
(Cert. 1232200003)
60h, unmonitored
NF Grade 3,
Class 1
SPC5330.320 +
SPCP333.300
(Cert. 1232200003)
60h, unmonitored
7.1.5 PSU LED Status
The following table lists the Smart PSU LED status information:
LED
MAINS
BATT 1 & 2
FUSE
LIMIT
STATUS
COLOUR
Green
Green
Red
Red
Green
Condition
Normal
On
On
Off
Off
On
Mains OK, battery charging
On
Flash
On
Mains Fail, Battery OK
Off
On
On
Mains OK, battery faulty or
not present
On
Off
On
Mains OK, battery faulty,
not present, or in deep
discharge protection mode
All LEDs Off.
Fuse Fail
On
On
Total Load Current
exceeded
On
On
PSU switcher failure
Off
Flash
