Engineer programming via the browser
17
Using the Fast Programmer
311
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
System Configuration File
The following options are available to manage the system configuration file:
Download
Downloads a configuration file from the controller.
Note: If an error message appears after clicking the download button, proceed as
follows:
1. Select Internet Options in the Tools menu.
2. Select the Advanced tab.
3. Mark the checkbox Do not save encrypted pages to disk.
4. Click Apply.
5. Click OK.
6. Click Download again.
When downloading a configuration file, the configuration settings are stored in a .cfg
file. This file can then be uploaded to other controllers to avoid lengthy programming
procedures.
Upload
Uploads a configuration file to the controller.
Backup
Stores a backup copy of the current configuration to flash.
Restore
Restores a backup copy of the current configuration from flash.
Users Data
The following options are available to manage users data:
Download
Click the button to Download the users data from the panel. A dialog box
asks you where you would like the save the users.csv file.
Upload
Click the Browse button to Upload users data to the panel. This must be a
.csv file format.
17.12 Using the Fast Programmer
The SPC Fast Programmer is a portable storage device that provides the engineer
with the ability to upload and download configuration files in a quick and convenient
manner. The Fast Programmer has two interfaces located on opposite ends of the
device:
SPC controller interface
This 10-pin serial interface is located at the top of the Fast Programmer and
connects directly to the Fast Programmer interface on the controller board. Once
connected, the engineer can upload and download files directly from the Fast
Programmer via the browser and keypad programming tools.
PC USB interface
This USB interface is located at the bottom of the Fast Programmer and connects
directly to the USB interface on a PC. Configuration and other files can be only be
copied between the PC and the Fast Programmer using the SPC Pro programming
tool.
