Installation & Configuration Manual
The amount of current from Aux output using a 10 Ah battery for
SPC43xx/SPC53xx/ SPC63xx is:
3.1.5 PD 6662:2010 Conformance Guidelines
This appendix contains all the criteria for the installation, and commissioning and
maintenance of the SPC System to enable it to conform to the PD 6662:2010
Standard.
3.1.5.1 Product scope
The scope of this document is aimed at the following components of the SPC
system:
SPC4320.320-L1 Grade 2 Controller
SPC5320.320-L1 Grade 2 Controller
SPC5330.320-L1 Grade 3 Controller
SPC5350.320-L1 Grade 3 Controller
SPC6330.320-L1 Grade 3 Controller
SPC6350.320-L1 Grade 3 Controller
SPCK420/421.100 LCD Keypad
SPCE452.100 Expander, 8 Relay Outputs
SPCE652.100 Expander, 8 Inputs / 2
Outputs
SPCP332.300 Smart PSU with I/O
Expander
SPCP355.300 Smart PSU with 8 Inputs / 2
Outputs Expander
SPCP333.300 Smart PSU with I/O
Expander
SPCN110.000 PSTN Module
SPCN310.000 GSM Module
3.1.5.2 Standards overview
Guidelines are provided for the implementation of PD 6662:2010 conformance for
an SPC system to the following relevant standards:
BS 4737-3.1:1977
BS 8243:2010
BS 8473:2006+A1:2008
BS EN 50131-1:2006+A1:2009
BS EN 50136-1-1:1998+A2:2008
BS EN 50136-1-2:1998
BS EN 50136-1-3:1998
BS EN 50136-2-1:1998 +A1:1998
BS EN 50136-2-2:1998
BS EN 50136-2-3:1998
BS EN 50131-3:2009
BS EN 50131-6:2008
DD 263:2010
DD CLC/TS 50131-7:2008
3.1.5.3 Methods for the completion of setting and unsetting
Methods of completion of setting (BS 8243:2010 - Clause 6.3)
Completion/Termination of the full setting procedure is achieved by any of the
following methods:
a) Shunt lock fitted to the final exit door
A shunt lock must be installed by the installer as follows:
