7
Smart PSU
SPCP355.300 Smart PSU
58
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Number
Description
1
Standard 12V Power output
2
Configurable, supervised, 12V DC logical switched output.
7.1.2 Batteries
7.1.2.1 Installing Batteries
This section describes the battery installation for the SPCP355.300 Smart PSU and
G5 Enclosure.
4K7
OP 6 – OP 8
SW 6 – SW 8
OV
Ext. Bell
OP 6 – OP 8
SW 6 – SW 8
OV
PIR
0V
12V
12V
0V
1
2
