Engineer programming via the keypad
Communication
140
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Glass Reset
Used to switch on the power for the glassbreak interface module and to remove power
in order to reset the device. The output is reset if a user enters their code, the zone is
not in the closed state, and the bells deactivated.
Confirmed holdup
Activates in the following scenarios for PD6662 compliance:
 two hold-up zone activations more than two minutes apart
 a hold-up zone and a panic zone activation more than two minutes apart
 If a hold-up zone and a tamper zone or a panic zone and a tamper zone activation
occurs within the two minute period
Full Engineer
Activates if an engineer is on site and the system is in full engineer mode.
* This output type can only indicate system wide events (no area specific events).
See also
 Configuring system latch and auto set outputs [➙ 202]
16.11 Communication
1. Scroll to COMMUNICATION and press SELECT.
2. Scroll to the desired programming option.
16.11.1 Serial Ports
The serial ports allow older style PCs to be connected to the system or other
peripheral equipment like printers.
1. Scroll to SERIAL PORTS.
2. Press SELECT.
3. Scroll to the serial port to be programmed.
4. Select the desired programming option shown in the table below.
5. Press BACK to exit.
TYPE
Determines if type is TERMINAL (system information) or PRINTER (SPC event log)
BAUD RATE
Determines the speed of the communication between the panel and the peripheral
equipment. Please note that the baud rate must be set the same as both items of
equipment.
DATA BITS
Determines the length of data packet to be transferred between the panel and the
peripheral equipment. Please note that the data bits must be set the same for both
items of equipment.
STOP BITS
Determines the number of stop bits at the end of the data packet. Please note that the
stop bits must be set the same for both items of equipment.
PARITY
Determines the parity (odd/even) of the data packet. Please note that the parity must
be set the same for both items of equipment.
FLOW
CONTROL
Determines if the data is under hardware (RTS, CTS) or software control (None).
Please note that the flow control must be set the same for both items of equipment.
16.11.2 Ethernet Ports
To program the Ethernet port:
1. Scroll to ETHERNET PORT.
