Applicable attributes to zone types
Installation & Configuration Manual
This attribute only applies to the KEYARM zone type. If set then the setting
state of the building will toggle on openings only.
This attribute only applies to the KEYARM zone type. If this attribute is set
then zone activation will Fullset the system/area. Apply this attribute if it is
intended that the user should only have the ability to FULLSET the system
from a keyarm zone.
This attribute only applies to the KEYARM zone type. If set then zone
activation will Unset the system/area. Apply this attribute if it is intended that
the user should only have the ability to UNSET the system from a keyarm
zone.
Allows a zone when opened, regardless of the mode to send an alarm to the
ARC in FF, CID, SIA and SIA extended. When areas are selected, the alarm
will only be sent to the ARC to which the area has been assigned to. This
would be a “UA” Unknown Alarm followed by the zone number and text if SIA
extended is selected. It will also send an SMS to the end user and engineer if
select to do so when the unconfirmed alarm filter is selected.
Allows an opening zone to be displayed on the system keypad. The alert led
should also activate. When areas are selected it will only be displayed on the
keypad which is assigned to the area in which the zone has been selected.
The alert may only be displayed on the keypad when the area is in the unset
mode and not in the Part A, Part B and set mode.
Allows an activated zone to operate the buzzer. This will operate the same as
the Tech Zone Display in the different setting modes and on systems with
areas.
Allows the zone to have a programmable delay. The delay is variable from 0
to 9999 seconds and will apply to all Tech Zones. The operation is the same
as the Mains Delay timer, if the zone is closed within the delay time, then no
alarm is sent to the ARC, no SMS is sent to the user and the Technical
Output will not trip.
NOTE: The Technical Output will not trip until the delay timer has expired.
Openings are reported only in armed mode.
If enabled and a fire alarm occurs, a Fire Pre-alarm timer is started and
internal bells and buzzers are activated. (See Timers [➙ 230].) If the alarm is
not cancelled within the timer duration, a fire alarm is confirmed, internal and
external bells are triggered and an event is sent to ARC.
If enabled, a Fire Recognition timer is activated which adds extra time to the
Fire Pre-alarm timer duration until a file alarm is reported for the zone. See
Timers [➙ 230].
Seismic Test/Automatic Sensor
Test
A Seismic zone type may be tested manually or automatically. This attribute
allows automatic testing to be enabled. Refer to the section on timers [➙ 230]
for details of how to configure the timer that determines how often the panel
tests any seismic zones that have this attribute set. The default value for the
timer is 7 days.
The ‘Timed’ attribute is used for Key Arm zones to delay the setting of an
area. The delay follows the exit timer for the area to which the key arm is
associated.
Select the configured verification zone to assign to this zone to trigger
audio/video verification.
If enabled, the keyarm device can set the system, automatically inhibiting all
open zones.
23.18 Applicable attributes to zone types
The following table shows which attributes are applicable to each zone type:
