Keypad user interface
SPCK620/623
98
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
– Autoarm
 System information
– Soaked zones
– Open zones
– Area state
– Low battery (sensor)
– Sensor lost
– WPA low battery
– WPA lost
– WPA test overdue
– Camera offline
– Fob low battery
– Xbus over current
– Installer name
– Installer phone
– Engineer enable
– Manufacture enable
– Reboot
– Hardware fault
– Aux over current
– Battery low
– Ethernet link
– System name
12.2.2 LED description
Description
Symbol
Color
Operation
Description
Information
Blue
On
The system or area cannot be set.
Forced setting is possible (faults or open
zones can be inhibited).
Flashing
The system or area cannot be set or
forced set (faults or open zones cannot
be inhibited).
Off
The system or area can be set.
Amber
Flashing
Engineer is on site.
User
Green
On
Assigned area is unset.
Flashing
Assigned area is Partset A / B
Off
Assigned area is fullset
Alarm
Red
On
Alarm
Flashing
-
Off
No alarm
Alert
Amber
On
-
Flashing
Trouble
Off
No trouble
Mains
Green
On
System ok
Flashing
Mains fault
!
