Engineer programming via the browser
Using the Fast Programmer
Installation & Configuration Manual
2. Press Next.
3. Click Continue Anyway.
At the end of the installation process, a window indicates that the
installation process is complete.
4. Click Finish.
For Windows 7
You have administration privileges.
SPCPro must be installed on the Windows 7 PC.
Connect the Fast Programmer to a USB interface on the PC.
The drivers are installed automatically
View SPC Fast Programmer
Open the Windows menu Start > Control panel > System > Device Manager.
The Fast Programmer driver will be listed under the Ports (COM & LPT)
directory as SPC USB Fast Programmer (COM X) (X = com port number).
17.12.3 Fast Programmer File Operations
Controller and peripheral firmware upgrades and custom language imports may be
done using the Fast Programmer and SPC Pro.
17.12.3.1 Accessing the Fast Programmer using the Keypad
1. Enter Full Engineer and scroll to UTILITIES > FAST PROGRAMMER.
2. Press SELECT.
3. Scroll and select the desired option:
Select desired file from list.
Select desired file from list.
Select desired file from list.
The panel searches for a valid controller firmware file. Once it finds
the firmware file, it will allow the user to select it and upgrade the
panel.
The panel searches for a valid peripheral firmware file. Once it finds
the firmware file, it will allow the user to select it and upgrade the
panel
A list of the language files available on the Fast Programmer is
displayed. Select the language required and press SELECT to
import the file.
17.12.3.2 Accessing the Fast Programmer using the Browser
1. Enter Full Engineer in browser programming and select the File programming
page.
2. Click Fast Programmer.
The options to upload and download files are displayed.
